20' Type IA Fiberglass Straight Posting Ladder

SPF20-1

Werner Co.

The SPF00-1 Posting ladders have 1" diameter solid aluminum hooks with aluminum rail shields at the top of the ladder. The large 9 3/4" hook opening allows for easy attachment in the field. Center anchor points distribute force to each rail, and fall protection tie-offs are located every 5 to 6' along the length of the ladder. GLAS MARK violator stripes allow for added visibility. The rounded aluminum hoop shoe with ribbed rubber pad provides solid footing. These ladders have a duty rating of 300 pounds and are made with non-conductive fiberglass side rails.

(click image to enlarge)
Quick Overview

    Features include:

  • 1" diameter solid aluminum hook with aluminum rail shield (large 9-3/4" hook opening allows for easy attachment)
  • 3" slip resistant Traction-Tred steps are double riveted and braced front and back
  • Center anchor points distribute force to each rail. Fall protection tie-offs located every 5' to 6' along the ladder
  • Glas*Mark violator stripes for added visibility
  • Rounded aluminum hoop shoe with ribbed rubber pad provides solid footing
Interested in this item or want more information?

Phone:
Email: Sales@48ws.com

Can't find what you want? Give us a call and we can help you find it.
Details

Dimensions

  • Rails Dimension: 3-5/16"
  • Flange Dimension: 1-3/16"
  • Rung Dimension: 2-7/8"
  • Base Width: 14-5/8"

  • Specifications

  • Size: 20'
  • Reach Height: 22'
  • Load Capacity: 300 lbs.
  • Type: Type IA Duty Rating
  • Performance Rating: 4 Star
  • Material: Fiberglass
  • Rung Type: Other
  • Foot Material: Slip-resistant pad
  • Number of Sections: 1
  • Certifications: ANSI A14.5 (2007); OSHA
  • Approx. Cu. Ft. Per Unit: 8.4
  • Approx. Shipping Wt. Lbs.: 58

  • Additional SPF00-1 Series Models:
    Model No.SizeReach Height Approx. Cu. Ft. Per Unit Approx. Shipping Wt. Lbs.
    SPF14-114'16'638
    SPF16-116'18'6.843
    SPF18-118'20'7.649
    SPF20-120'22'8.458
    Additional Information
    Manufacturer: Werner Co.
